Quick Installation Using the Bash Script

A Linux operating system is recommended for running abcdesktop.io.

Linux or macOSWindows

Prerequisites

A Kubernetes cluster in the Ready state
The kubectl command-line tool configured to communicate with your cluster
openssl and curl installed on the local machine (required only for the kubectl-based installation method)

Running the Installation Script

Download and execute the latest release installation script:

curl -sL https://raw.githubusercontent.com/abcdesktopio/conf/main/kubernetes/install-4.4.sh |bash

The following video demonstrates how to install abcdesktop.io on a freshly provisioned Kubernetes cluster using the bash script.

Expected stdout output:

show details

[INFO] abcdesktop install script namespace=abcdesktop
[OK] kubectl version
[OK] openssl version
[OK] kubectl create namespace abcdesktop
writing RSA key
writing RSA key
[OK] abcdesktop_jwt_desktop_payload keys created
writing RSA key
[OK] abcdesktop_jwt_desktop_signing keys create
writing RSA key
[OK] abcdesktop_jwt_user_signing keys create
[OK] create secret generic abcdesktopjwtdesktoppayload
[OK] create secret generic abcdesktopjwtdesktopsigning
[OK] create secret generic abcdesktopjwtusersigning
[OK] label secret abcdesktopjwtdesktoppayload
[OK] label secret abcdesktopjwtdesktopsigning
[OK] label secret abcdesktopjwtusersigning
[OK] downloaded source https://raw.githubusercontent.com/abcdesktopio/conf/main/kubernetes/abcdesktop-4.4.yaml
[OK] downloaded source https://raw.githubusercontent.com/abcdesktopio/conf/main/reference/od.config.4.4
[OK] kubectl create configmap abcdesktop-config --from-file=od.config -n abcdesktop
[OK] label configmap abcdesktop-config abcdesktop/role=pyos.config
role.rbac.authorization.k8s.io/pyos-role created
rolebinding.rbac.authorization.k8s.io/pyos-rbac created
serviceaccount/pyos-serviceaccount created
configmap/configmap-mongodb-scripts created
secret/secret-mongodb created
deployment.apps/mongodb-od created
deployment.apps/memcached-od created
deployment.apps/router-od created
deployment.apps/nginx-od created
deployment.apps/speedtest-od created
deployment.apps/pyos-od created
deployment.apps/console-od created
deployment.apps/openldap-od created
endpoints/desktop created
service/desktop created
service/memcached created
service/mongodb created
service/speedtest created
service/pyos created
service/console created
service/http-router created
service/website created
service/openldap created
[INFO] waiting for deployment/console-od available
[OK] deployment.apps/console-od condition met
[INFO] waiting for deployment/memcached-od available
[OK] deployment.apps/memcached-od condition met
[INFO] waiting for deployment/mongodb-od available
[OK] deployment.apps/mongodb-od condition met
[INFO] waiting for deployment/nginx-od available
[OK] deployment.apps/nginx-od condition met
[INFO] waiting for deployment/openldap-od available
[OK] deployment.apps/openldap-od condition met
[INFO] waiting for deployment/pyos-od available
[OK] deployment.apps/pyos-od condition met
[INFO] waiting for deployment/router-od available
[OK] deployment.apps/router-od condition met
[INFO] waiting for deployment/speedtest-od available
[OK] deployment.apps/speedtest-od condition met
[INFO] list all pods in namespace abcdesktop
NAME                            READY   STATUS    RESTARTS   AGE
console-od-844c749f85-vbbb7     1/1     Running   0          32s
memcached-od-d4b6b6867-tbfgf    1/1     Running   0          33s
mongodb-od-5d996fd57b-tcn45     1/1     Running   0          33s
nginx-od-796c7d7d6b-lgnjb       1/1     Running   0          33s
openldap-od-567dcf7bf6-h2nq9    1/1     Running   0          32s
pyos-od-8d4988b56-vcd7z         1/1     Running   0          32s
router-od-f5458658-b52hj        1/1     Running   0          33s
speedtest-od-7fcc9649b4-qllr7   1/1     Running   0          32s
[INFO] Setup done
[INFO] Checking the service url on http://localhost:30443
[INFO] service status is down
[INFO] Looking for a free TCP port from 30443
[OK] Get a free TCP port from 30443
[INFO] If you're using a cloud provider
[INFO] Forwarding abcdesktop service for you on port=30443
[INFO] For you setup is running the command 'kubectl port-forward nginx-od-796c7d7d6b-lgnjb --address 0.0.0.0 30443:80 -n abcdesktop'
[OK] Port-Forward successful
[OK] Please open your web browser and connect to

[INFO] http://localhost:30443/

The installation script performs the following steps in order:

Creates the abcdesktop Kubernetes namespace.
Generates RSA key pairs for JWT signing and payload encryption using openssl.
Creates all required Kubernetes resources — ServiceAccount, RBAC roles, Services, Deployments, Secrets, and ConfigMaps — from the abcdesktop.yaml manifest.
Downloads the default configuration file od.config and creates the abcdesktop-config ConfigMap.

Note: This installation does not include application images. The desktop launches with only the minimal default applications available in the dock.

Once the script completes, open a web browser and navigate to http://localhost:30443/.

Changing the Default Namespace

To deploy abcdesktop.io into a namespace other than the default abcdesktop, download the script and pass the --namespace option:

wget https://raw.githubusercontent.com/abcdesktopio/conf/main/kubernetes/install-4.4.sh
chmod 755 install-4.4.sh

Run the script with a custom namespace:

./install-4.4.sh --namespace superdesktop

show details

[INFO] abcdesktop install script namespace=superdesktop
[OK] kubectl version
[OK] openssl version
[OK] kubectl create namespace superdesktop
[OK] create secret generic abcdesktopjwtdesktoppayload
[OK] create secret generic abcdesktopjwtdesktopsigning
[OK] create secret generic abcdesktopjwtusersigning
[OK] label secret abcdesktopjwtdesktoppayload
[OK] label secret abcdesktopjwtdesktopsigning
[OK] label secret abcdesktopjwtusersigning
[OK] use local file abcdesktop.yaml
[OK] use local file od.config
[OK] updated abcdesktop.yaml file with new namespace superdesktop
[OK] updated abcdesktop.yaml file with new fqdn superdesktop.svc.cluster.local
[OK] updated od.config file with new namespace superdesktop
[OK] updated od.config file with new fqdn superdesktop.svc.cluster.local
[OK] kubectl create configmap abcdesktop-config --from-file=od.config -n superdesktop
[OK] label configmap abcdesktop-config abcdesktop/role=pyos.config
[OK] default account is created
[OK] role.rbac.authorization.k8s.io/pyos-role created
rolebinding.rbac.authorization.k8s.io/pyos-rbac created
serviceaccount/pyos-serviceaccount created
configmap/configmap-mongodb-scripts created
secret/secret-mongodb created
deployment.apps/mongodb-od created
deployment.apps/memcached-od created
deployment.apps/router-od created
deployment.apps/nginx-od created
deployment.apps/speedtest-od created
deployment.apps/pyos-od created
deployment.apps/console-od created
deployment.apps/openldap-od created
endpoints/desktop created
service/desktop created
service/memcached created
service/mongodb created
service/speedtest created
service/pyos created
service/console created
service/http-router created
service/website created
service/openldap created
[OK] pyos-serviceaccount account is created
[INFO] waiting for deployment/console-od available
[OK] deployment.apps/console-od condition met
[INFO] waiting for deployment/memcached-od available
[OK] deployment.apps/memcached-od condition met
[INFO] waiting for deployment/mongodb-od available
[OK] deployment.apps/mongodb-od condition met
[INFO] waiting for deployment/nginx-od available
