Controllers

Overview

abcdesktop.io is built on the Model-View-Controller (MVC) design pattern. MVC decouples the internal representation of data from how that data is presented to and accepted from the user, enabling a clean separation of concerns across the pyos control plane.

Controller Reference

The following table lists all pyos controllers and their responsibilities:

Controller	Description
`AccountingController`	Exposes per-user accounting and session metrics in JSON format
`AuthController`	Handles all user authentication flows
`ComposerController`	Manages CRUD operations for core services — e.g., `createDesktop`, `createApplication`
`CoreController`	Returns system configuration data and user-facing messages
`ManagerController`	Provides management operations (e.g., adding or removing application images); used exclusively by the console service
`UserController`	Returns authenticated user profile information

Access Control Configuration

Controller access is configured in the controllers dictionary in the od.config file. Access can be restricted by source IP address (permitip) and/or API key (apikey).

controllers : {
    'AccountingController': {
        'apikey': [ 'fPCdPNcCafec4lXm3M' ],
        'permitip': [ '10.0.0.0/8', '172.16.0.0/12', '192.168.0.0/16', 'fd00::/8', '169.254.0.0/16', '127.0.0.0/8' ]
    },
    'ManagerController': {
       'database_acl': [ 'get', 'put', 'delete' ],
        'apikey': [ 'fQDbvjCafec4l', 'KzH23EZjCZSfsd9'],
        'permitip': [ '10.0.0.0/8', '172.16.0.0/12', '192.168.0.0/16', 'fd00::/8', '169.254.0.0/16', '127.0.0.0/8' ]
    },
    'AuthController' :      { 'permitip': None },
    'ComposerController' : { 'requestsallowed' : { 'getdesktopdescription': True } },
    'CoreController' :      { 'permitip': None },
    'UserController' :      { 'permitip': None }
}

By default, AccountingController and ManagerController are restricted to source IP addresses from RFC 1918 private ranges (RFC 1918) and the IPv6 Unique Local Address range (RFC 4193). All other controllers are accessible without restriction by default.

Filter	Type	Description
`permitip`	list of CIDR strings	Restricts access to requests originating from the listed subnets. Set to `None` to disable IP filtering. Example: `['10.0.0.0/8', '172.16.0.0/12']`
`apikey`	list of strings	Restricts access to requests presenting a valid API key in the `X-API-Key` HTTP header. Set to `None` to disable API key filtering. Example: `['fPCdPSSj8gZri1Ncmg']`

When a request is denied due to an IP source filter violation, the HTTP response is:

{"status": 403, "status_message": "403 Forbidden", "message": "Request forbidden -- authorization will not help"}

curl Request Examples

Request with `X-API-Key` Header

List all registered application images:

curl -X GET -H 'X-API-Key: fQDbvjCafec4l' -H 'Content-Type: text/javascript' http://localhost:30443/API/manager/images

Expected response:

{}

Register a new application image:

curl -X POST -H 'X-API-Key: fQDbvjCafec4l'  -H 'Content-Type: text/javascript' http://localhost:30443/API/manager/image -d@xeyes.d.4.4.json
